AUSA-A12-AFS-5WB-Kit A12 AFS -5.0 Wheel Base Kit (Awesomatix)

Description

AUSA-A12-AFS-5WB-Kit A12 AFS -5.0 Wheel Base Kit

AwesomatixUSA is putting together a 3 piece kit to ensure everything necessary is ordered to support the new AFS Adjustable Front Suspenion Set

Includes

• A12-AFS
• A12-C1201AFS-5.0
• A12-C1205AFS-5.0

AwesomatixUSA Team Driver Quotes

• “New front end is dialed”
• “Everything is adjustable without using any shims. Ride height adjustment with spring pressure. Droop is set with a grub screw on the bottom plate.  Camber and caster set at the top. Everything is much much easier to set and get perfect.”
• “AFS front end used to great success at the recent NYGP and USIC races! Makes setting camber/caster/droop/ride height easier than ever without the need of .2mm shims laying everywhere around your pit!”

Manufacturer’s description for A12-AFS-

The optional A12-AFS set is our next-generation front suspension system for the A12X / A12WC platforms.
Its main advantage: you can adjust caster, camber, ride height and droop with the front wheels installed – without changing any shims, caster posts or any disassembly.

Important: The A12-AFS set cannot be used with the standard C1205X or C1201X components.

Key Feature:

• – Full front-end tuning without removing the wheels.
• – Faster, cleaner adjustments compared to traditional 1/12 pan-car suspensions.
• – Compatible with standard 1/12 setup stations or an angle gauge for camber.
• – Camber range: ±1.75°
• – Selectable caster angles: 3°, 4°, 5°, 6°
• – Stepless ride-height adjustment
• – Stepless downstop adjustment

Compatibility & Required Parts:
